Industry Inserted Bag Pulse Dust Removal Equipment

  • Industry Inserted Bag Pulse Dust Removal Equipment
  • Industry Inserted Bag Pulse Dust Removal Equipment

Industry Inserted Bag Pulse Dust Removal Equipment

    Payment Type: L/C,T/T
    Terms of Trade: FOB,CIF
    Min. Order: 1 Piece/Pieces
    Delivery Time: 30 Days
    Packaging: carton
    Transportation: Ocean,Land
    Port: Xingang,China

Basic Info

Model No.: UF-0001

Product Description

Operating Principle:

Pulse bag filter is a kind of dry dust removal device, also known as the filter separator, it is to use fiber knitting bag filter element to capture the dust in the gas solid particles of dust removal device, its action principle is the dust through the filter cloth fiber were intercepted by inertia effect contact with fiber, collected on the filter bag dust regularly by clearing the ash removal device and fall into ash hopper, and then through the ash system to draining out .

The advantages of DMC pulse jet dust collector :

1, the dust collector have strong abilities of ash and dust removal ,high efficiency, low emission concentration, air leakage rate is small, less energy consumption, less consumption of steel, covers an area of less, stable and reliable operation, good economic benefit.
2, because use chamber stop pulse wind blowing dust, blowing a can achieve the purpose of soot cleaning thoroughly, so the soot cleaning cycle extended, the energy consumption of soot cleaning, compressed air consumption can be greatly reduced.At the same time, the filter bag and pulse valve fatigue also reduced accordingly, thus exponentially increase the filter bag and the service life of the valve.
3, maintenance and change bags can be constantly system fan, system under the condition of normal operation of the chamber.Filter bag mouth of the elastic ring, sealed performance is good, strong and reliable.Bag filter bag keel using polygon, reducing the friction and keel, prolong the life span of the bag, and convenient for unloading bags.
4, using the upper suction bag in bag when pulled out after the skeleton, dirty bag bottom ash hopper into enclosure, removed from the manhole, improved in bags of operating conditions.
5, box adopts the design of gas tightness, good sealing, inspection door with good sealing material, production process with kerosene leakage, leakage rate is very low.
6, inlet and outlet duct layout is compact, small flow resistance.

Scope of application:

pulse bag filter used machinery, metallurgy, rubber, flour, chemical, pharmaceutical, carbon, building materials, mining, electroplating and other industries.


filting area(m2) air volume(m3/h) filting airspeed(m/min) working resistance(Pa) dust removing pressure(Mpa)
DMC-32 30 2880-4800 1.5-2.5 800-1800 0.4-0.6
DMC-48 48 4320-7200 1.5-2.5 800-1800 0.4-0.6
DMC-60 60 5400-9000 1.5-2.5 800-1800 0.4-0.6
DMC-72 72 6480-10800 1.5-2.5 800-1800 0.4-0.6
DMC-90 90 8100-13500 1.5-2.5 800-1800 0.4-0.6
DMC-120 120 10800-18000 1.5-2.5 800-1800 0.4-0.6
DMC-150 150 13000-22500 1.5-2.5 800-1800 0.4-0.6
DMC-180 180 16200-27000 1.5-2.5 800-1800 0.4-0.6


18900-31500 1.5-2.5 800-1800 0.4-0.6
DMC-250 250 22500-37500 1.5-2.5 800-1800 0.4-0.6
DMC-270 270 24300-40500 1.5-2.5 800-1800 0.4-0.6
DMC-300 300 27000-45000 1.5-2.5 800-1800 0.4-0.6
DMC-340 340 30400-51000 1.5-2.5 800-1800 0.4-0.6
DMC-420 420 37800-63000 1.5-2.5 800-1800 0.4-0.6
DMC-500 500 45000-75000 1.5-2.5 800-1800 0.4-0.6
DMC-600 600 54000-90000 1.5-2.5 800-1800 0.4-0.6
DMC-740 740 66600-111000 1.5-2.5 800-1800 0.4-0.6
DMC-870 870 78300-130500 1.5-2.5 800-1800 0.4-0.6
DMC-1000 1000 90000-150000 1.5-2.5 800-1800 0.4-0.6
DMC-1100 1100 99000-165000 1.5-2.5 800-1800 0.4-0.6
